Accuracy is maintained for all angles over the range of 0 to 359.9999 degrees with a resolution of 0.0001º. This instrument is designed to provide 2 arc-seconds of accuracy at the operating frequency of 400 Hz and may be used with reduced accuracy up to 5 kHz. When the model 540 input is connected to the standard line to line levels of 11.8, 26, 90, 115 Vrms, it provides a null output in either the synchro or the resolver mode. Its unique bridge circuit design provides a constant null voltage gradient over the entire angular range. The Model 540 Synchro/Resolver Bridge provides the user with the ability to measure the electrical shaft position of either synchros or resolvers as components or as transducers within an operating system. The board incorporates up to four Synchro/Resolver measurement channels and up to four instrument-grade Synchro/Resolver simulation channels, or up to eight embedded grade Synchro/Resolver simulation channels that can be used independently and/or. The maximum channel density of the 76CS1 is fixed at: eight S/D (maximum measurement.

NORTH ATLANTIC SYNCHRO RESOLVER SERIES

Size: 19" W x 5.25" H x 15" D (481mm x 133mm x 380mm) NAI’s 65CS4 is a Synchro/Resolver Simulation & Measurement Instrument on a single-slot VXI board. The North Atlantic Industries 76CS1 Series features seperate transformer isolated Synchro/Resolver-to-digital tracking converters, separate transformer isolated Digital to Synchro/Resolver converters, optional internal 5VA reference, and extensive diagnostics.

One of the outputs on each channel can be grounded without affecting performance. These channels can incorporate up to four Digital-to-Synchro/Resolver Simulation Converters with 1.5, 2.2, or 3 VA drive capability, or either two or four Digital-to-LVDT/RVDT Simulation Converters.

Single set of input terminals for synchro and resolver NAI’s 75DS2 is a Synchro/Resolver Simulation Board with four independent, isolated channels.

NORTH ATLANTIC SYNCHRO RESOLVER FULL

Full 0-360° rotation with direct angular readout.Resolution to 0.0001° 2 arc-second accuracy (NIST traceable).
